前言Foreword

鋁的導熱性能在金屬中排名第三，僅次于銀和銅，它的W/ (m X k)值可達到193，是10#碳素鋼(46.4)的4.16倍;它的重量很輕，比重2.71g/cm  ，是10#碳素鋼的(7.8g/cm  )的約三分之一。

鋁的耐腐蝕性能高于鐵，尤其是添加了一定量的其他金屬后，它的抗氧化、抗老化（鹽霧試驗）性能，可達到10#碳素鋼的5倍以上。

鋁的加工性能非常優越，它可以通過熱擠壓工藝制成單根超長的無縫鋁管，避免了用鋼管作為換熱芯體進行焊接而產生的缺陷，可以避免鋼的高報廢率，因而以鋁代鋼，它具有以下優點：

1．因?yàn)樗鼘?dǎo)熱系數比10#碳素鋼高了4倍，所以在同等條件下鋁合金的換熱效果比10#碳素鋼更佳，其性價比更高;

2．在防水垢問題上鋁合金管要好于鋼管、鋼管換熱器的盤管是碳鋼經過熱浸鋅處理過的，其表面很粗糙容易結水垢，日積月累后水垢會越來越厚，會嚴重影響盤管的換熱效果，即使我們也標配有電子水處理器,但其效果也不是很明顯，而鋁合金管表面很光滑不容易結垢，且鋁的熱膨脹系數遠大于鋼管，即使鋁合金管表面產生水垢也會在水淋狀態下自行剝離脫落，會大大增加盤管機芯的使用壽命,確保換熱效果不受影響；

3．10#碳素鋼經過僅200小時的耐腐蝕試驗就銹跡嚴重，使用壽命大概在2—4年，但防銹鋁合金卻可以通過6000小時的耐腐蝕試驗，其使用壽命可達到5年以上；

4．目前在行業里蒸發式冷凝器的排管焊接有兩種方法：(1)用彎頭與直管焊接，整個機芯盤管就有無數個焊接接頭，(2)用鋼帶卷成圓管進行焊接，整個機芯盤管從頭到尾都有一條焊縫，焊縫處最容易腐蝕，所以鋼管機芯焊接位置最容易泄露，因焊接位置貫穿整個機芯，如機芯中間泄露則無法進行修補，我公司自行生產的鋁合金管單管可達150m長，其長度足夠一次彎曲成型使用，因此單管中間無焊縫，焊接位置只在集流管上，都在機芯外側，因此即使焊縫處泄漏，也可隨時補修；

5．由于蒸發冷安裝經常放置到屋頂位置，有些大功率的蒸發冷設備自身重達10多噸，放在屋頂?shù)脑?，建筑往往達不到承重要求而需要進行加固，耗資甚巨，但防銹鋁合金管做的蒸發冷重量只是鋼管的60%左右，重量大大減輕，放置在屋頂?shù)脑挻蠖鄶?shù)建筑無需加固，即使要加固的話工程量也很小可以省去很多時間和資金。



Foreword

The thermal conductivity of aluminum is ranked third in the metal,after the silver and copper, its W/(m X K)value can reach 193,is 10# carbon steel(46.4)4.16 times; it is light in weight, the proportion of 2.71g/cm  ,10# carbon steel(7.8g/cm  )of about 1/3.

      Aluminum corrosion resistance than iron,especially added a certain amount of other metals, its antioxidant,anti-aging(salt fog test)performance,can reach more than 5 times the 10# carbon steel.

      Processing properties of aluminum is very superior,seamless tubeswhich can be single long made by hot extrusion process,avoids the defects caused by welding steel pipe as heat exchange core body,canavoid high scrap steel,thus with aluminum and steel,it has the following advantages:

      1. because of its thermal conductivity than 10# carbon steel high 4 times,so the heat exchange efficiency of aluminum alloy under the same conditions than 10# carbon steel is better,the price is higher;

      2．in the water fouling problem of aluminium alloy pipe is better than steel pipe, coil heat exchanger tube is carbon steel after hot dip zinc treated, the surface is very rough easy scaling, after days and months multiplyingscale will be more and more thick, will seriously affect the effect of heat exchange coil，even though we also comes standard with electronic waterprocessor,but its effect it is not obvious．a(chǎn)nd the aIuminum alloy tubesurface is very smooth and not easy to scale．a(chǎn)nd the aIuminum thermal expansion coefficient is much larger than the steeI pipe．a(chǎn)lumjnum alloytube surface even produce scale willbe in the water state to peel off，wilI greatly increase the service life of the coll core，Ensure that the heating effect is not affected

    3．1 0#carbon steel corrosion test after only 200 hours of rust seriously,service life is about 2-4years，but the antirust aluminum alloy can be acorrosion test for 6000 hours,its service life can reach more than 5 years；

    4．is currently in the industry of evaporative condenser pipe welding in two ways：(1)with the elbow and straight pipe welding，the entire core coilhas a welded joint，(2)are welded steel pipe to form a round，the whole movemenf from A to Z coil has a weld,weld the most prone to corrosion,so steel core welding position most easily leak，because the welding position throughout the movement，such as the core intermediate leakscannot repair,aluminum alloy our company’s own production tubes up to 150m long，and the length of a bending forming enough use, because there is no weld this pipe，welding position only in the manifold，inmovement outside，so even if the weld leakage，but also can repair；

    5．due to evaporative cooling instailation often placed in the position of the roof．the evaporative cooling equipment and some high power selfweighing more than 1 0 tons,on the roof,the building cannot reach thebearing requirements and needs strengthening．expensive,but theantirust aluminum alloy tube evaporative cooling steel tube weight is onlyabout 60％，weight greatly reduced，placed in the roof of the words most building without reinforcement．construction quantity if reinforcement is also very small can save a lot of time and money．
